Designed to make everyday transfer and care tasks easier.
Sara Flex enables a single caregiver to assist a patient or resident from a seated to a standing position, in one natural movement.
Promotes comfort and security throughout and at the completion of the sit-to-stand movement.
FACILITATING A RANGE OF KEY TRANSFERS AND CARE TASKS
Designed with ease of use for the single caregiver in mind, with no adjustments required.
NATURAL FORWARD MOVEMENT FOR THE PATIENT
Forward movement, combined with the flexible leg support, enables
a natural and comfortable sit-to-stand movement.
DSDC DEMENTIA DESIGN ACCREDITED PRODUCT
The Dementia Services Development Centre (DSDC) at the University of Stirling has reviewed Sara Flex and awarded it a DSDC Product Accreditation Rating Class 1B.
Curved design with a soft and flexible surface that supports the lower legs and knees throughout the sit-to-stand movement. Requiring no adjustments, the large surface caters for a broad range of patients while delivering good comfort.
FLEXIBLE SILICONE LEG STRAP
Positioned low and with and multiple adjustment options to ensure patients can be securely positioned from a seated to a standing position.
EASY-TO-USE HAND CONTROL WITH DISPLAY
The hand control is on a long flexible cord that enables the caregiver to stay close to the patient throughout the transfer.
Curved handle enables the caregiver to choose where to hold.
The contrast-coloured angled patient handle positions the hands, wrists and elbows throughout the sit-to-stand movement.
LOW HORIZONTAL FOOTPLATE
Keeping the patient’s feet close to the ground means their knees are not raised too high, making it easier to stand.
Built in electronic scale shows the patient’s weight on the display of the hand control.
|Max safe working load kg||200 kg|
|Max safe working load lb||440 lb|
|Lift Weight (incl battery) kg||53,6 kg|
|Lift Weight (incl battery) lb||118 lb|
|Min total storage height mm||1162 mm|
|Min total storage height in||45 3/4 in|
|Min lifting height mm||991 mm|
|Min lifting height in||39 in|
|Max lifting height mm||1518 mm|
|Max lifting height in||59 3/4 in|
|External width legs closed mm||660 mm|
|External width legs closed in||26 in|
|External width legs open mm||1029 mm|
|External width legs open in||40 1/2 in|
|Internal width leg closed mm||530 mm|
|Internal width leg closed in||20 7/8 in|
|Internal width leg open mm||899 mm|
|Internal width leg open in||35 3/8 in|
|Leg clearance (floor to top of legs) mm||108 mm|
|Leg clearance (floor to top of legs) in||4 1/4 in|
|Chassis clearance (floor to bottom of chassis) mm||23 mm|
|Chassis clearance (floor to bottom of chassis) in||1 in|
|Lift total length mm||996 mm|
|Lift total length in||39 1/4 in|
|Turning radius mm||1208 mm|
|Turning radius in||47 1/2 in|
|Lifter protection class||IP24|
|Handcontrol protection class||IPX7|
|Battery Charge Indicator||yes|
|Service meter - displays the total usage of time (hours)||yes|
|Emergency stop and system failure override||yes|
|Automatic saftety cut out if lowered onto an obstacle||yes|
|Low friction castors, the rear two with breaks||yes|
Category: Instructions for use
File name: 04.KL.00.EN_5.pdf
Size: 2.28 Mb
